Basic Info.
Measurement Object
Flatness
Range
0～100mm
Resolution
0.001mm
Precision
0.005mm
Measure Method
Manual
Accuracy
A
Precision Measuring Device
Precision Measuring Device
Certification
JIS, DIN, ISO
Customized
Customized
Transport Package
Wooden Box
Specification
3000*1000
Origin
China
HS Code
90179000
Product Description
Specification | Specification Length × Width × Thickness (mm) | Weight (kgs) | Flatness tolerance (um) | ||
| 00 grade | 0 grade | 1 grade | ||
| 300 × 200 × 50 | 17 | 3 | 6 | 12 |
| 300 × 300 × 50 | 19 | 3 | 6 | 12 |
| 400 × 300 × 70 | 25 | 3 | 6 | 12 |
| 400 × 400 × 70 | 48 | 3.5 | 6.5 | 13 |
| 630 × 400 × 100 | 76 | 3.5 | 7 | 14 |
| 630 × 630 × 100 | 155 | 4 | 8 | 16 |
| 800 × 500 × 130 | 156 | 4 | 8 | 16 |
| 1000 × 630 × 130 | 284 | 4.5 | 9 | 18 |
| 1000 × 750 × 150 | 338 | 5 | 9 | 18 |
| 1000 × 1000 × 150 | 450 | 5 | 10 | 20 |
| 1600 × 1000 × 200 | 963 | 6 | 12 | 24 |
| 2000 × 1000 × 200 | 1200 | 6.5 | 13 | 26 |
| 1600 × 1600 × 300 | 2312 | 6.5 | 13 | 26 |
| 2000 × 1600 × 300 | 2890 | 7 | 14 | 28 |
| 2500 × 1600 × 300 | 3612 | 8 | 16 | 32 |
| 3000 × 2000 × 500 | 9030 | 9 | 18 | 36 |
| 4000 × 2000 × 500 | 12040 | 11 | 22 | 44 |
| 6000 × 2000 × 700 | 25284 | 15 | 30 | 60 |
RFQ
1.Can I order one piece granite surface plate?
if you want small size less than 800x800,it's would delivery by air express. mos times express cost is higher than granite cost.
so we don't suggest you buy one small size from us.
2. if your granite surface plate have certifications ?
Yes , each of granite surface plate has it's certification.if you need we can send sample for you
3. How much does granite surface plate weight?
(Lengthx width xHeight )mmx3x1000= weight granite kg
4. why dose granite have color steaks,spots and seams ?
Seams and color streaks occur occasionlly&naturally in granite stone. it is not uncommon for granite plates of large sizes to
include cosmetic non-conformities,which we endeavor to keep to a minimum. we can assure you that such visible disconformities are
carefully examined before,during and after the manufacturing process for actual or potential problems due to non-conforming
material. Our goal during this inspection process is to insure that we are following our own internal quality standards.
5. Can you put my company name and logo on your product ?
How should I clean my precision granite products
6.Why I get the granite accuracy is not good ?
Due to different temperature granite accuracy wil be change , before you use it,please put it in a uniform temperature space over
24hours, it's request temperature (20 ±5 )ºC
